Don't leave your production data lying around: anonymize it with

DbToolsBundle

Simon Mellerin

  • 🧑‍💻️ · Web developer · PHP/Symfony · Vue.js
  • 🗺️ · from Nantes, France

Pierre Rineau

  • 🧑‍💻️ · Senior backend engineer · PHP/Symfony · Vue.js
  • 🗺️ · from Nantes, France

Makina Corpus

  • Digital Service Company
  • ~50 people
  • working exclusively with FLOSS

Makina Corpus

  • Services
  • Products
  • Training

DbToolsBundle

Anonymization

What's next

Anonymize? 🤔

3 Common Issues

  • Easy configuration for data anonymization
  • A simple anonymization workflow
  • Making anonymization fast

DbToolsBundle

Built from real-world needs

DbToolsBundle

A set of Console Commands

  • Backup


    								db-tools backup

  • Restore


    								db-tools restore

  • Anonymize


    								db-tools anonymize

  • Display statistics


    								db-tools stats


DbToolsBundle

Works on top of most popular Database vendors:

postgresql sqlite mariadb mysql

Performance

Try it on our benchmark app:

  • 4 Database connections

    (PostgreSQL, SQLite, MySQL, MariaDB)
  • 3 Entities to anonymize
    • Customer: email · password · lastname · firstname · age
    • Address: a complete postal address (5 fields)
    • Order: telephone · email · amount · note

Performance

Customer Address Order PostgreSQL SQLite MariaDB MySQL
100k - - ~5s ~7s ~20s ~53s
1 000k - - ~16s ~16s ~1m 23s ~36m 56s
- 200k - ~6s ~10s ~26s ~42s
- - 1 000k ~16s ~11s ~1m 15s ~25m 1s
100k 200k - ~7s ~10s ~32s ~1m 16s
100k 200k 1 000k ~24s ~25s ~1m 40s ~36m 47s

Performance

  • Anonymizing with SQL only
  • One update query per table
  • Build with a complete query builder

Flavors

Flavors


					$ vendor/bin/db-tools anonymize --local-database


					$ php bin/console db-tools:anonymize --local-database


					$ docker compose run dbtools anonymize --local-database


					$ php artisan db-tools:anonymize --local-database


DbToolsBundle

Anonymization

What's next

Setting Up Anonymization

Map each table's column you want to anonymize with an Anonymizer.

  • Email
  • Password
  • Int
  • Float
  • String
  • Firstname
  • Lastname
  • Address
  • etc...

Setting Up Anonymization


				# db_tools.config.yaml

				connections: "pgsql://username:password@hostname:port/database?version=16.0&other_option=..."

				storage_directory: ./var/db_tools

				backup_expiration_age: '6 months ago' # default '3 months ago'

				backup_excluded_tables: ['table1', 'table2']

				# ...



In a single YAML configuration file

Setting Up Anonymization


						# db_tools.config.yaml

						# ...

						anonymization:
								default:
										customer:
												email_address: email
												password:
													anonymizer: password
													options: {algorithm: 'sodium', password: '123456789'}
												level:
														anonymizer: string
														options: {sample: ['none', 'bad', 'good', 'expert']}
												age:
														anonymizer: integer
														options: {min: 10, max: 99}
						#...


With YAML, from a list of various anonymizers

Setting Up Anonymization

On Doctrine Entities, from a list of various anonymizers


						namespace App\Entity;

						use Doctrine\ORM\Mapping as ORM;
						use MakinaCorpus\DbToolsBundle\Attribute\Anonymize;

						#[ORM\Entity()]
						#[ORM\Table(name: 'customer')]
						class Customer
						{
								#[ORM\Id]
								#[ORM\GeneratedValue]
								#[ORM\Column]
								private ?int $id = null;

								#[ORM\Column(length: 180, unique: true)]
								#[Anonymize(type: 'email')]
								private ?string $emailAddress = null;

								#[ORM\Column(length: 180, unique: true)]
								#[Anonymize(
									type: 'password',
									['password' => '123456789']
								)]
								private ?string $password = null;

								#[ORM\Column]
								#[Anonymize(
									type: 'integer',
									options: ['min' => 10, 'max' => 99]
								)]
								private ?int $age = null;

								#[ORM\Column(length: 255)]
								#[Anonymize(
									type: 'string',
									options: ['sample' => ['none', 'bad', 'good', 'expert']]
								)]
								private ?string $level = null;

								#[ORM\Column]
								private ?\DateTime $lastLogin = null;

								// ...
						}


Setting Up Anonymization

Check your config with:


					db-tools anonymization:dump-config


					Table: customer
					---------------

					----------- ------------ ---------------------------------------------------------------------------------
						Target      Anonymizer   Options
					----------- ------------ ---------------------------------------------------------------------------------
						email       email
						password    password
						lastname    lastname
						firstname   firstname
						age         age          min: 10, max: 99
						level       string       sample: [none, bad, good, expert]
					----------- ------------ ---------------------------------------------------------------------------------


A GDPR-friendly workflow


					user@prod:~$ db-tools restore --list


					user@preprod:~$ scp user@prod:/path/to/prod.dump /tmp/prod.dump


					user@preprod:~$ db-tools anonymize /tmp/prod.dump


					user@local:~$ scp user@preprod:/tmp/prod.dump /tmp/prod-anonymized.dump


					user@local:~$ db-tools restore --filename /tmp/prod-anonymized.dump


Custom Anonymizers


					namespace App\Anonymizer;

					use MakinaCorpus\DbToolsBundle\Anonymization\Anonymizer\AbstractAnonymizer;
					use MakinaCorpus\DbToolsBundle\Attribute\AsAnonymizer;

					#[AsAnonymizer(
							name: 'my_anonymizer', // a snake case string
							pack: 'my_app', // a snake case string
							description: 'Describe here if you want how your anonymizer works.'
					)]
					class MyAnonymizer extends AbstractAnonymizer
					{

						// ...


How does it work under the hood?

  1. One update query per table to anonymize
  2. Each anonymizer alter the update query
  3. Queries are built with PHP Query Builder

How does it work under the hood?

temporary alteration of your SQL schema

How does it work under the hood?

the SQL query in deep


					UPDATE
						"customer"
					SET
						"nom" = "sample_1"."value",
						"civilite" = "sample_2"."value"

					FROM "customer" AS "_target_table"

					LEFT JOIN (
						SELECT
							"value",
							ROW_NUMBER() OVER (ORDER BY random()) AS "rownum"
						FROM "sample_1"
						LIMIT 171224
					) AS "sample_1"
					ON MOD("_target_table"."_db_tools_id", 589)
						= "sample_1"."rownum"

					LEFT JOIN (
						SELECT
							"value",
							ROW_NUMBER() OVER (ORDER BY random()) AS "rownum"
						FROM "sample_2"
						LIMIT 171224
					) AS "sample_2"
					ON MOD("_target_table"."_db_tools_id", 2)
						= "sample_2"."rownum"

					WHERE
						"client"."_target_table" = "_target_table"."_db_tools_id"
					;


DbToolsBundle

Anonymization

What's next

Roadmap

  • Easy-to-configure datalist

    (from csv, json...)
  • Faker pack & languages packs

  • Pre/Post anonymization SQL queries

  • Whitelist conditions for rows

  • New core anonymizers

  • Other Database vendors ?

Contribute

  • 📢 · Share
  • 🪲 · Report
    • Missing documentation
    • Issues in code
  • 🧑‍💻 · Code

We need you to make DbToolsBundle awesome!

Thanks, any question?

Resources:

Lien Open Feedback:
